International tutorials on Digital Tools for Built Heritage diagnosis and monitoring (DT4BH)

June 20, 2023 - June 21, 2023
Summer School

POLYTECH Orléans - Amphi Langevin-38
12 rue de Blois - Site Galilée
45100 Orléans


Recent advances in 3D scanning technologies of buildings, combined with their progressive appropriation by an increasing number of users, make it possible today to consider the systematic production of data for historic buildings. Processing of these large amounts of multimodal data is essential for the monitoring and the diagnosis of built heritage. Thus, Historic Building Information Modelling (HBIM) appears today as a promising and critical strategy for making the best of the collected data.

However, due to the specificity of historic constructions (large-scale, complex and/or non-standardized architecture/materials/construction process, specific applications for monitoring), HBIM still faces challenges before being fully operational. This scientific event proposes to address these challenges by sharing the latest research in this field.

This Summer School is organised in the framework of the Advanced Technology Higher Education Network Alliance (ATHENA European University)

Topics :

•    Laser scanning acquisition
•    Photos (terrestrial / drone) acquisition
•    3D Reconstruction from laser and/or photos
•    Application 1: GIS for mappings on orthophotos
•    Application 2: Machine Learning for degradation detection



  • Xavier Brunetaud,  LaMé / University of Orléans, University of Tours, INSA CVL - FR
    From laser scan to GIS mapping

  • Manolis Maravelakis,  Hellenic Mediterranean University - GR
     From photos to 3D modeling

  • Belen RiveiroUniversity of Vigo - ES
    Processing of laser data for HBIM

  • Sylvie Treuillet,  PRISME / University of Orléans, INSA CVL - FR
    Analysis and diagnostic tools using image processing and deep learning


This event is for those interested in keeping up with the latest developments in digital technologies for preservation and diagnostic support of historic buildings, as well as future trends. Graduate students, post-graduate students, architects, and industry practitioners are the typical profiles of attendees. However, there are no formal prerequisites in terms of academic degrees, so those who are less or more advanced in their careers will also be welcome.


The event includes 4 courses of 2h30 to 3h each providing complementary and transdisciplinary knowledge. The learning of knowledge will be facilitated by a small number of participants with practical application with high performance equipment. The organizers emphasize the importance of face-to-face interaction and networking in this type of research training event with fruitful discussion with leading researchers. An open session will allow participants to make short presentations or posters of their work in progress.


Practical Information

APPLY FOR FREE REGISTRATION FEES (For members of ATHENA European Universities)

The full cost of participation in the 2 days of tutorials: training (theoretical and practical), accommodation and meals can be offered to a limited number of participants. These participants will only have to provide their own transportation to Orleans (France).
To apply, send an email to with your

  • - curriculum (1 or 2 pages max.)
  • - motivation letter  regarding your current or future research project (1/2 page max.)
  • - letter of recommendation

Upon justified request, additional funds for transportation costs can be obtained.

Deadline to apply: 25 May 2023
Results of the selection process for free participation : 30 May 2023

Non-members of ATHENA European Universities

> For the others, a participation fee of 100 euros is requested to cover the 2 days of training courses (theoretical and practical) and meals (2 lunches, dinner on Monday and coffee breaks). The participants must provide their own accomodation and transportation to Orléans (France). Please register on the website.



Tuesday 20th June 2023

09:00 Registration

Session 1

Xavier Brunetaud,  LaMé / University of Orléans, University of Tours, INSA CVL - FR

From laser scan to GIS mapping

  • 09:30 Handling the laser scanner, on-site scan test
  • 10:00 Assembling scan projects with Faro SCENE, point cloud export, orthoprojection export
  • 11:00 Manipulating the point cloud with CloudCompare, meshing
  • 11:45 Using QGIS to annotate orthophotos
  • 12:30 Lunch

Session 2

 Sylvie Treuillet & Xavier Desquesnes, PRISME / University of Orléans, INSA CVL - FR

14:00 - 17:00 Analysis and diagnostic tools using image processing and deep learning

19:30 Social dinner - Les Pissenlits par la Racine

Wednesday 21st June 2023

Session 3

Belen Riveiro & Yago Cruz, University of Vigo - ES

09:30 - 12:30 Processing of laser data for HBIM

Session 4

Nikolaos Bolanakis,  Hellenic Mediterranean University - GR

14:00 - 17:00 From photos to 3D modeling
